DOOSAN
Closed-loop FFH
90 m3/h / 50 bar
60 m3/h / 74 bar
67 m3/h / 71 bar
45 m3/h / 106 bar
Overall dimensions (LxWxH)
6000 x 2100 x 2540 mm
Weight
5700 kg
Manufacturer
DOOSAN
Model
PU086T
Engine power
151 kW / 2200 rpm
Torque
826 Nm / 1400 rpm
Max concrete pump output (rod side)
90 m3/h / 50 bar
Max concrete pump output (piston side)
60 m3/h / 74 bar
Max concrete pump pressure (rod side)
67 m3/h / 71 bar
Max concrete pump pressure (piston side)
45 m3/h / 106 bar
Hydraulic system
Closed-loop FFH
Main hydraulic pump
A4VG125
Concrete cylinder (diameter x length)
D.200 x 1600 mm
Hydraulic cylinder (diameter x length)
D.110 x 1600 mm
S-valve type
S2015
Concrete hopper volume
600 L
Fuel tank volume
250 L
Hydraulic oil tank volume
350 L
Max aggregate size
40 mm
Axle / wheels
1 axle / 2 single wheels
Outriggers
4 hydraulic outriggers
4 hydraulic outriggers, 1 front auxiliary outrigger with support wheel for safe, efficient operation and multi-terrain adaptability
DOOSAN 6-cylinder engine for powerful pumping capacity
Equipped with a REXROTH – Germany closed-loop hydraulic system (FFH) for efficiency and economy
REXROTH – Germany hydraulic swing pump, providing continuous and stable flow with superior durability
Central control cabinet, modular design, allowing easy monitoring of equipment operating status
High-pressure Φ60 concrete cylinder / agitator shaft with a new design, equipped with a booster shock absorber, extremely safe and durable
Equipped with a convenient cleaning system (located on top of the pump): High-pressure hydraulic water pump (20 bar), water tank (200 liters)
LINCOLN – USA automatic greasing system, combined with a manual pump, increasing safety in case of automatic greasing system failure
Tilt angle balance indicator, for easy monitoring of equipment stability
Newly designed hopper system, with 2 hydraulic motors controlling agitator blades on both sides, preventing concrete segregation and clogging
S2015 valve – Large opening, prevents aggregate segregation and clogging, high durability
Dynamic and static wear plates made of high-hardness Tungsten, resistant to strong friction for extended periods and harsh conditions
Concrete pump cylinder with chrome plating inside, high hardness, resistant to wear and scratches
